SPS-512DMX-4CH
MODEL: SPS-512DMX-4CH
- Controller Based Design
- Smooth & Flicker Free Dimming
- Can Operate with 1~4 Channel
- Compact, Light Weight & Easy Connection
- Designed To operate with Constant Voltage LED
- Can be used for CV LED Strip RGB, RGBW, RGBA
- 1 Year Warranty
| Input from LED Driver : | 12~24VDC |
| Input Signal : | DMX512 |
| Output Channel : | 1~4 Channels |
| Output Power : | 360W @ 12Vdc |
| Output Voltage : | 12~24VDC |
| Output Current : | 10A per 3 Channel. 8A per 4 Channel. |
| Dimension (L x W x H) : | 67 x 30 x 20 mm |
| IP Rating : | IP20 |
| Operating Temp. : | -20 to +50 Deg. C |
- Update Soon..
